ANVL UKON R4T

Original price was: $179.00.Current price is: $152.15.

ANVL UKON R4T V2 is a micro Sig Sauer Romeo 4T type rifle mount that incorporates a single focal plane absolute co-witness backup iron sight package. It utilizes a standard type AR-15 adjustable front sight post. It has the ability to adjust elevation. The user can adjust elevation to be point of aim, point of impact for subsonic rounds while still running the red dot for super sonic and vice versa.

(1 customer review)

Out of stock

Join the waitlist to be emailed when this product becomes available

30-Day Manufacturing Warranty

ANVL UKON R4T is a micro Sig Sauer Romeo 4T type rifle mount that incorporates a single focal plane absolute co-witness backup iron sight package. It utilizes a standard type AR-15 adjustable front sight post. It has the ability to adjust elevation. The user can adjust elevation to be point of aim, point of impact for subsonic rounds while still running the red dot for super sonic and vice versa. It can be used as an absolute co-witness as well for a backup if the red dot fails. Because it is a single focal plane, and it is so close together for a sight picture; the irons actually act like a backup red dot. The mount is constructed from 6061 aluminum with a type 3 hard coat.

Weight: 1.8oz
Height: 1.68in
Width: 1.32in
Length: 3.47in

DISCLAIMER: ANVL UKON mounts are an emergency backup iron sight system. These were designed as a military requirement to fulfill the backup iron sight requirement while keeping rail space open for the operator. The intended use is within fifty yards or much less, in a CQB capacity; if the end users Red Dot sight is damaged, battery has died, or never powered on. This optic Mount system relies on true mechanical zero between the optic Mount, Rail and Barrel to have accurate windage.

DISCLAIMER: Torque Spec is 35-37 in lb for the 10-24 Clamp Screws. Accessories should always be installed by a professional.

ANVL UKON mounts are built and constructed to be a perfect mechanical zero from mount to rail. Make sure that your optic is seated correctly, and tighten down on the truest mechanical zero you can get. When mounting the optic Mount, make sure the amount is completely seated and the picatinny rail is tight against the non screw head side of the rail before tightening.

Reasons for windage to be off: Loose tolerances picatinny rail, out of spec tolerances picatinny rail, non-con Centric Barrel, mounting the optic mount to a polymer picatinny rail riveted to a sheet metal dust cover, poor tolerancing between barrel and picatinny rail.

Disclaimer: All ANVL products should be installed by a professional gunsmith. ANR DESIGN IS not responsible for poor Gunsmithing installation techniques and damage to personal property.

Check out the video below!



1 review for ANVL UKON R4T

  1. James (verified owner)

    Put this on my Galil 5.45 pistol. Love the look and size of the mount. Very clean, compact package. Can’t speak to ar15s but, when mounted the irons are off paper at 15m. I would pay more for a version with adjustable windage.

    • Alex Costa

      Galil rails tend to be out of spec often because they are a bolt on, to a piece of sheet metal, that is free float without the a secure way. My personal Galil Ace 545 is dead nuts on. Bummer.
